Fully Automatic Stretch Blow Molding Machine: An Introduction
Are you a merchant looking for a reliable supplier of high-quality blow molding machines at competitive rates? If yes, your search ends here. We are a leading manufacturer based in China with vast experience in designing, producing, and selling fully automatic stretch blow molding machines to merchants in various countries outside China. Our fully automatic stretch blow molding machines are perfect for the pet bottle, cosmetic, and food and beverage industries.
Product Description
Our fully automatic stretch blow molding machine is carefully designed and engineered to provide optimal performance and efficiency. This machine is equipped with a user-friendly interface, making it easy to use and operate. The machine comes with a robust mold structure and is capable of producing various shapes and sizes of PET containers.
Our fully automatic stretch blow molding machine utilizes advanced technology, including servo motors and microchip control, to ensure fast and precise high production rates. This machine features a unique heating system that guarantees consistent and uniform heating, leading to a superior quality finished product. The machine also features a safety mechanism ensuring safe and continuous operation.
Salient Features
1. Efficient Production – Our fully automatic stretch blow molding machine produces high-quality PET containers at a high production rate.
2. Pollution-Free – The production process does not emit toxic fumes or pollutants and is, therefore, environmentally friendly.
3. User-Friendly – Our machine is user-friendly with a simple operation process that requires minimal expertise to operate.
4. High-Quality – Our molding machines are of superior quality and produce high-quality finished products that meet the industry's standards.
5. Low Maintenance – Our fully automatic stretch blow molding machine requires low maintenance and is easy to fix, which translates to lower repair costs.
6. Cost-Effective – Our molding machines are cost-effective, providing an affordable option for merchants looking to increase their production capacity.
7. Versatility – Our molding machines can produce various shapes and sizes of PET containers to satisfy different market needs.
Why Choose Our Stretch Blow Molding Machine?
Our fully automatic stretch blow molding machines are designed and built to provide complete customer satisfaction. Our products are of exceptional quality and are manufactured using top-of-the-range materials and advanced technology. The machines are versatile, producing various sizes, shapes, and types of PET containers. We provide excellent customer service, delivery, and post-sales support to ensure our clients are satisfied.
Conclusion
In conclusion, our fully automatic stretch blow molding machine is a product worth investing in as a merchant. Our machines provide efficient, fast, and high-quality production of PET containers at an affordable cost. Additionally, our machines guarantee user-friendliness, low maintenance, and safe operation. We provide excellent customer service and post-sale support to ensure complete customer satisfaction. Contact us today to place your order and benefit from our top-quality stretch blow molding machines.
A preform Feeding system
The conveyor put the preform from the barrel to the entire machine, then the preform are automatic arranged in order for feeding in a single way, uses servo drive chain feeding system adopt FESTO rotation cylinder to divide into blank movement and positioning. The clipper picks preforms and place them on the transfer system.The way will avoid preforms jamming orwasting preforms.
B Transfer system
The traditional linear machine is normal transmitted by chain or air cylinder, when cylinder drives, the speed is slow, efficiency is down, when chain drives, it is too noisy. AOK series composed of the casting nylon slider with servo motor drive, providing fast and which can meet environmental requirements.
C The heating system
Preforms are feeding to the heating system with the chain moving, together with minimum center between two preforms, in order to make shortest distance to heat, saving more energy preforms go with rotation mode heat and cooling, to ensure heating averagely.
 |
 |
 |
|
|
Model |
Unit |
AOK-6000L |
|
Clamping System |
(Number of cavity) |
cavities |
6 |
|
(clamping unit) |
KG |
65000 |
|
|
(mold stroke) |
mm |
130 |
|
|
(stretch stroke) |
mm |
320 |
|
|
(Bottom stroke) |
mm |
30 |
|
|
(Cavity pitch) |
mm |
114.3 |
|
|
(heating pitch) |
mm |
114.3 |
|
|
(Number of holder) |
PCS |
114 |
|
|
Container |
(Max.container volume) |
ltr |
1.5 |
|
(Max. neck diameter) |
mm |
38 |
|
|
(Max.prefrom height) |
mm |
140 |
|
|
(Max.container diameter) |
mm |
95 |
|
|
(Max.container height) |
mm |
320 |
|
|
(theoretical output) |
B.P.H |
5500-6000 |
|
|
Electrical System |
(heating oven) |
UNITS |
8 |
|
(box*channel) |
Floor |
8*9 |
|
|
(Number of lamp) |
pcs |
72 |
|
|
(heating power) |
KW |
86.4 |
|
|
(installed power) |
KW |
95 |
|
|
(voltage) |
Voltage |
220v/380V/3 |
|
|
Air System |
(operating pressure) |
kg/cm2 |
7 |
|
(blowing pressure) |
mpa |
3.5 |
|
|
(high pressure air consuming) |
M³/min |
6.4 |
|
|
(power) |
KW |
88 |
|
|
Chiller System |
(temperature) |
°C |
10-15 |
|
(pressure) |
Mpa |
0.4 |
|
|
(flow rate) |
L/min |
80 |
|
|
(heating power) |
HP |
5 |
|
|
Machine |
(L×W×H) |
M |
5.6*2.2*1.8 |
|
(machine weight) |
KG |
6500 |
|
